Description

Specifications:

SOURCE

SMD RGB 3-in-1 LEDs

Color Resolution: 8 bits per color (24 bit per pixel)

Viewing Angle: 120 x 120 degrees

Pixels Per Meter: 60 pixels

Pixel Pitch (pixel center-to-center) 16.5mm

PWM (Pulse Width Modulation): 44,000Hz

CONNECTIONS

4pin Power/Data In/Out

SIZE / WEIGHT

Length: 19.7” (500mm)

Width: 1.26” (32mm)

Height: 2.64” (67mm)

Weight: 1.54 lbs. (0.7kg)

ELECTRICAL

Max Power Consumption: 6W

APPROVALS

CE | cETLus

Specifications and documentation subject to change without notice.
