LCG WIDMX Receiver (1)

LCG Widmx Receiver

$170.00

LCG WF WIDMX  is user-friendly operation that simplifies all the complex communication protocols makes it possible for the users to plug and play.  2.4GHz ISM Band, license-free worldwide,  FHSS with 79 Channels, interference-free operation, 32-bit ARM processor, DMA transfer without delay,  Built-in Wireless Solution compatibility mode, Group Mode, easy plug-and-play operation; Pairing Mode, supports more transmitter universes .

Add to Wishlist
Continue Shopping SKU: LCG-WIDMX-RC Categories: , ,

Description

Features:

Four mode to choose from, as bellow ;
1. Red mode ; Custom signal compatible such as WIDMX.
2. Green mode ; Sweden compatibility (Wireless
Solution) receiver
3. Blue mode ; Sweden compatible (Wireless Solution )
transmitter
4. Yellow mode ; Standard 2.4G compatible
5. Purple mode: W-DMX G4 Transmit
• Band: 2.402GHz – 2.480GHz, ISM, 79 channels
• pread spectrum: FHSS, 1100 hops / sec
• Modulation: GFSK
• Maximum Transmit Power: 23dBm
• Receiver Sensitivity: -94dBm

Specifications:

Power: DC 5V ± 10%
IP20
Size：212 x 18 x 18 mm



www.soundlitesales.com is a Canadian authorized LCG Dealer.

Warranty

LCG Widmx Receiver

Manufacturer’s Warranty:

1-year limited warranty

Downloads

LCG WIDMX Receiver User Manual
